SBR30UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
LMK30UU (SAMICK)
SME30GUU (Nippon bearing)

Inner Diameter (d): 30 mm
Highth (F): 56 mm.
Width (W): 70 mm.
Length (L): 70 mm.
Clamping bolts (S): M8.

This rail does not require end fasteners, as the shaft is supported along its entire length by an aluminum support with holes for mounting on the frame. With this design, there is no shaft deflection over long lengths, so SBR guides can be used for CNC machines with large working areas, unlike conventional polished shafts.

Diameter: 35 mm.
Length: 5900 mm.
Tolerance: h6.
Material: C45.

SBR35LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Inner Diameter (d): 35 mm
Highth (F): 63 mm.
Width (W): 80 mm.
Length (L): 155 mm.
Clamping bolts (S): M8.

SBR35UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
LMK35UU (SAMICK)
SME35GUU (Nippon bearing)

Inner Diameter (d): 35 mm
Highth (F): 63 mm.
Width (W): 80 mm.
Length (L): 80 mm.
Clamping bolts (S): M8.

SBR shafts are precision-ground cylindrical guides mounted on an aluminum support rail, which simplifies installation and increases structural rigidity. This support ensures stable alignment and reduces bending, allowing SBR shafts to operate reliably under medium loads in CNC machines, 3D printers, and various automated systems.

Cross References:
R1014 040 00 (Rexroth)
FTSN40GW (FLI)
TSNW40 (INA)

Diameter: 40 mm.
Length: 5900 mm.
Tolerance: h6.
Material: C45 hardened steel.

SBR40LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Inner Diameter (d): 40 mm
Highth (F): 72 mm.
Width (W): 90 mm.
Length (L): 175 mm.
Clamping bolts (S): M10.

SBR35UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
LMK40UU (SAMICK)
SME40GUU (NB)

Inner Diameter (d): 40 mm
Highth (F): 72 mm.
Width (W): 90 mm.
Length (L): 90 mm.
Clamping bolts (S): M10.

SBR shafts are precision-ground cylindrical guides mounted on an aluminum support rail, which simplifies installation and increases structural rigidity. This support ensures stable alignment and reduces bending, allowing SBR shafts to operate reliably under medium loads in CNC machines, 3D printers, and various automated systems.

Cross References:
R1014 050 00 (Rexroth)
FTSN50GW (FLI)
TSNW50 (INA)

Diameter: 50 mm.
Length: 5900 mm.
Tolerance: h6.
Material: C45 hardened steel.

SBR50LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Inner Diameter (d): 50 mm
Highth (F): 92 mm.
Width (W): 120 mm.
Length (L): 215 mm.
Clamping bolts (S): M10.

SBR50UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
LMK50UU (SAMICK)
SME50GUU (NB)

Inner Diameter (d): 50 mm
Highth (F): 92 mm.
Width (W): 120 mm.
Length (L): 215 mm.
Clamping bolts (S): M10.

SC08VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC08VUU (SAMICK)

Inner Diameter: 8 mm
Highth (H): 22 mm.
Width (W): 34 mm.
Length (L): 15,4 mm.
Clamping bolts (S1): M4.

SC10VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC10VUU (SAMICK)

Inner Diameter: 10 mm
Highth (H): 26 mm.
Width (W): 40 mm.
Length (L): 19,5 mm.
Clamping bolts (S1): M5.

SC12VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC12VUU (SAMICK)

Inner Diameter: 12 mm
Highth (H): 28 mm.
Width (W): 42 mm.
Length (L): 20,5 mm.
Clamping bolts (S1): M5.

SC13VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC13VUU (SAMICK)

Inner Diameter: 13 mm
Highth (H): 30 mm.
Width (W): 44 mm.
Length (L): 20,5 mm.
Clamping bolts (S1): M5.

SC16VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC16VUU (SAMICK)

Inner Diameter: 16 mm
Highth (H): 38,5 mm.
Width (W): 50 mm.
Length (L): 23,5 mm.
Clamping bolts (S1): M5.

SC20VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC20VUU (SAMICK)

Inner Diameter: 20 mm
Highth (H): 41 mm.
Width (W): 54 mm.
Length (L): 27,4 mm.
Clamping bolts (S1): M6.

SC25VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC25VUU (SAMICK)

Inner Diameter: 25 mm
Highth (H): 51,5 mm.
Width (W): 76 mm.
Length (L): 37,4 mm.
Clamping bolts (S1): M8.

SC30VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC30VUU (SAMICK)

Inner Diameter: 30 mm
Highth (H): 59,5 mm.
Width (W): 78 mm.
Length (L): 40,9 mm.
Clamping bolts (S1): M8.

SC35VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC35VUU (SAMICK)

Inner Diameter: 35 mm
Highth (H): 68 mm.
Width (W): 90 mm.
Length (L): 45,3 mm.
Clamping bolts (S1): M8.

SC40VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC40VUU (SAMICK)

Inner Diameter: 40 mm
Highth (H): 78 mm.
Width (W): 102 mm.
Length (L): 56,4 mm.
Clamping bolts (S1): M10.

SC50VUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SC50VUU (SAMICK)

Inner Diameter: 50 mm
Highth (H): 102 mm.
Width (W): 122 mm.
Length (L): 68,9 mm.
Clamping bolts (S1): M10.

SCE12LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE12WUU (SAMICK)

Inner Diameter: 12 mm
Highth (F): 30 mm.
Width (W): 44 mm.
Length (L): 77 mm.
Clamping bolts (S): M5.

SCE12UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE12UU (SAMICK)

Inner Diameter: 12 mm
Highth (F): 30 mm.
Width (W): 44 mm.
Length (L): 39 mm.
Clamping bolts (S): M5.

SCE16LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE16WUU (SAMICK)

Inner Diameter: 16 mm
Highth (F): 38,5 mm.
Width (W): 50 mm.
Length (L): 89 mm.
Clamping bolts (S): M5.

SCE16UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE16UU (SAMICK)

Inner Diameter: 16 mm
Highth (F): 38,5 mm.
Width (W): 50 mm.
Length (L): 44 mm.
Clamping bolts (S): M5.

SCE20LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE20WUU (SAMICK)

Inner Diameter: 20 mm
Highth (F): 41 mm.
Width (W): 54 mm.
Length (L): 106 mm.
Clamping bolts (S): M6.

SCE20UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE20UU (SAMICK)

Inner Diameter: 20 mm
Highth (F): 41 mm.
Width (W): 54 mm.
Length (L): 53 mm.
Clamping bolts (S): M6.

SCE25LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE25WUU (SAMICK)

Inner Diameter: 25 mm
Highth (F): 51,5 mm.
Width (W): 76 mm.
Length (L): 136 mm.
Clamping bolts (S): M8.

SCE25UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE25UU (SAMICK)

Inner Diameter: 25 mm
Highth (F): 51,5 mm.
Width (W): 76 mm.
Length (L): 67 mm.
Clamping bolts (S): M8.

SCE30LUU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE30WUU (SAMICK)

Inner Diameter: 30 mm
Highth (F): 59,5 mm.
Width (W): 78 mm.
Length (L): 154 mm.
Clamping bolts (S): M8.

SCE30UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE30UU (SAMICK)

Inner Diameter: 30 mm
Highth (F): 59,5 mm.
Width (W): 78 mm.
Length (L): 76 mm.
Clamping bolts (S): M8.

SCE35UU linear ball bearing bushing is designed to ensure smooth and precise linear motion, minimize friction, and extend operational service life.

Cross references:
SCE35UU (SAMICK)

Inner Diameter: 35 mm
Highth (F): 68 mm.
Width (W): 90 mm.
Length (L): 80 mm.
Clamping bolts (S): M8.
