RGH55CAZ0H (HIWIN)
SRG55VTTP (THK)
R1821 (Rexroth)

RGH55CAZAH (HIWIN)
SRG55VTTC1P (THK)
R1821 (Rexroth)

RGH55CAZBH (HIWIN)
SRG55VTTC0P (THK)
R1821 (Rexroth)

Delivery Terms:
- Cutting and docking are included in the product price and are performed using specialized equipment in accordance with the manufacturer's specifications to ensure precision and reliability.
- The price is specified per millimeter of length.
- If required, please specify the distance from the rail end to the first mounting hole (DISTANCE TO END "E").
Note: the maximum length of a single rail cannot exceed 4000 mm. Longer rails will be supplied in multiple precisely docked sections.

Cross References
RGR55T4000H (HIWIN)
SRG55-4000L-P (THK)

Double bidirectional End seal + Bottom seal

Double bidirectional End seal + Bottom seal + Scraper

SL lubricator unit is designed with an oil reservoir which equipped with a high-density fiber net.

Bidirectional End seal + Bottom seal + Scraper

RGW65CCZ0H (HIWIN)
SRG65ATTP (THK)
R1851 (Rexroth)

RGW65CCZ0P (HIWIN)
SRG65ATTP (THK)
R1851 (Rexroth)

RGW65CCZAH (HIWIN)
SRG65ATTC1P (THK)
R1851 (Rexroth)

RGW65CCZBH (HIWIN)
SRG45ATTC0P (THK)
R1851 (Rexroth)

RGW65HCZ0H (HIWIN)
SRG65LATTP (THK)
R1853 (Rexroth)

RGW65HCZAH (HIWIN)
SRG65LATTC1P (THK)
R1853 (Rexroth)

RGW65HCZBH (HIWIN)
SRG65LATTC0P (THK)
R1853 (Rexroth)

RGH65HAZ0H (HIWIN)
SRG65VTTP (THK)
R1824 (Rexroth)

RGH65HAZAH (HIWIN)
SRG65VTTC1P (THK)
R1824 (Rexroth)

Delivery Terms:
- Cutting and docking are included in the product price and are performed using specialized equipment in accordance with the manufacturer's specifications to ensure precision and reliability.
- The price is specified per millimeter of length.
- If required, please specify the distance from the rail end to the first mounting hole (DISTANCE TO END "E").
Note: the maximum length of a single rail cannot exceed 4000 mm. Longer rails will be supplied in multiple precisely docked sections.

Cross References
RGR65R4000H (HIWIN)
SRG65-4000L-P (THK)

Delivery Terms:
- Cutting and docking are included in the product price and are performed using specialized equipment in accordance with the manufacturer's specifications to ensure precision and reliability.
- The price is specified per millimeter of length.
- If required, please specify the distance from the rail end to the first mounting hole (DISTANCE TO END "E").
Note: the maximum length of a single rail cannot exceed 4000 mm. Longer rails will be supplied in multiple precisely docked sections.

Cross References
RGR65T4000H (HIWIN)
SRG65-4000L-P (THK)

Single row cylindrical roller bearing, single direction for axial loads, separable, brass cage.
Product analogs:
NJ 316 ECM SKF
NJ316-E-XL-M1 FAG

The PM-0016-N is a high-performance digital output module. Featuring 16 isolated NPN (open collector) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 16 digital outputs
Output Type: NPN (open collector)
Nominal Voltage: 24 VDC
Max Output Current: Typically 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between channels and logic circuitry
Connection: Push-in or terminal block type connectors for secure wiring
Status Indication: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0016-P is a high-performance digital output module. Featuring 16 isolated PNP (source type) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 16 sourcing (PNP) digital outputs
Output Type: PNP (source type)
Nominal Voltage: 24 VDC
Max Output Current: Up to 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between field outputs and logic circuit
Status Indicators: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0016-R is a 16-channel relay output module. Each output channel features an independent electromechanical relay, allowing the module to switch a wide range of AC or DC voltages and currents, including inductive loads such as solenoids, contactors, and motors.
The PM-0016-R is for applications requiring galvanic isolation, reliable switching of high-voltage or high-current loads, and noise immunity.

Key Features
Channels: 16 relay outputs
Output Type: Electromechanical, SPST-ON (Form A)
Nominal Voltage: 250 VAC / 30 VDC
Max Output Current: Typically up to 2 A per channel
Isolation: High-voltage isolation between relay outputs and control logic
Status Indicators: LED indicators for real-time output status monitoring
Connection: Terminal block
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0032-N is a high-performance digital output module. Featuring 32 isolated NPN (open collector) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 32 digital outputs
Output Type: NPN (open collector)
Output Voltage: 24 VDC
Max Output Current: Typically 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between channels and logic circuitry
Connection: Terminal block
Status Indication: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0032-N-1 is a high-performance digital output module. Featuring 32 isolated NPN (open collector) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 32 digital outputs
Output Type: NPN (open collector)
Output Voltage: 24 VDC
Max Output Current: Typically 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between channels and logic circuitry
Connection: MIL connector
Status Indication: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)
