Single row cylindrical roller bearing, single direction for axial loads, separable, brass cage.
Product analogs:
NJ 316 ECM SKF
NJ316-E-XL-M1 FAG

Cross References:
SBR25UU, SBR25LUU
TBR25UU, TBR25LUU

The PM-0016-N is a high-performance digital output module. Featuring 16 isolated NPN (open collector) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 16 digital outputs
Output Type: NPN (open collector)
Nominal Voltage: 24 VDC
Max Output Current: Typically 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between channels and logic circuitry
Connection: Push-in or terminal block type connectors for secure wiring
Status Indication: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0016-P is a high-performance digital output module. Featuring 16 isolated PNP (source type) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 16 sourcing (PNP) digital outputs
Output Type: PNP (source type)
Nominal Voltage: 24 VDC
Max Output Current: Up to 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between field outputs and logic circuit
Status Indicators: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0016-R is a 16-channel relay output module. Each output channel features an independent electromechanical relay, allowing the module to switch a wide range of AC or DC voltages and currents, including inductive loads such as solenoids, contactors, and motors.
The PM-0016-R is for applications requiring galvanic isolation, reliable switching of high-voltage or high-current loads, and noise immunity.

Key Features
Channels: 16 relay outputs
Output Type: Electromechanical, SPST-ON (Form A)
Nominal Voltage: 250 VAC / 30 VDC
Max Output Current: Typically up to 2 A per channel
Isolation: High-voltage isolation between relay outputs and control logic
Status Indicators: LED indicators for real-time output status monitoring
Connection: Terminal block
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0032-N is a high-performance digital output module. Featuring 32 isolated NPN (open collector) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 32 digital outputs
Output Type: NPN (open collector)
Output Voltage: 24 VDC
Max Output Current: Typically 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between channels and logic circuitry
Connection: Terminal block
Status Indication: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0032-N-1 is a high-performance digital output module. Featuring 32 isolated NPN (open collector) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 32 digital outputs
Output Type: NPN (open collector)
Output Voltage: 24 VDC
Max Output Current: Typically 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between channels and logic circuitry
Connection: MIL connector
Status Indication: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-0032-N-2 is a high-performance digital output module. Featuring 32 isolated NPN (open collector) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.

Key Features
Channels: 32 digital outputs
Output Type: NPN (open collector)
Output Voltage: 24 VDC
Max Output Current: Typically 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between channels and logic circuitry
Connection: Fujitsu connector
Status Indication: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-1600 is a 16-channel digital input module designed by Leadshine for use in modular industrial automation systems. It provides reliable, high-speed detection of discrete signals from field devices such as sensors, switches, and buttons. Each input channel is electrically isolated to ensure robust performance and protection against industrial electrical noise.

Key Features
Channels: 16 digital inputs
Input Types: Sourcing (PNP) or sinking (NPN)
Input Voltage: 24 VDC (typical operating range: 12–30 VDC)
Input Current: Typically 3–7 mA per channel
Isolation: Optical isolation between inputs and control logic
Response Time: Fast signal detection (<1 ms)
Connection: Removable terminal blocks for easy installation and maintenance
Status Indicators: LED indicators for all input channels
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-1616-N is a digital I/O module. Designed for space-efficient automation systems, it allows seamless integration of sensors, switches, actuators, and signal devices within a unified control platform.
The inputs are optically isolated for improved noise immunity and signal integrity, while the outputs are transistor-based, enabling reliable control of low-voltage DC loads.

Key Features
Channels:
16 digital inputs
16 digital outpus
Input Types: Sourcing (PNP) or sinking (NPN)
Output Type: NPN (open collector)
Output Voltage: 24 VDC
Max Output Current: 0.5 A per output channel
Isolation: Optical isolation for both inputs and outputs
Connection: Terminal block
Status Indicators: Individual LEDs for all input and output channels
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-3200 is a 32-channel digital input module. It provides reliable, high-speed detection of discrete signals from field devices such as sensors, switches, and buttons. Each input channel is electrically isolated to ensure robust performance and protection against industrial electrical noise.

Key Features
Channels: 32 digital inputs
Input Types: Sourcing (PNP) or sinking (NPN)
Input Voltage: 24 VDC (typical operating range: 12–30 VDC)
Input Current: Typically 3–7 mA per channel
Isolation: Optical isolation between inputs and control logic
Response Time: Fast signal detection (<1 ms)
Connection: Removable terminal blocks for easy installation and maintenance
Status Indicators: LED indicators for all input channels
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-3200-1 is a 32-channel digital input module. It provides reliable, high-speed detection of discrete signals from field devices such as sensors, switches, and buttons. Each input channel is electrically isolated to ensure robust performance and protection against industrial electrical noise.

Key Features
Channels: 32 digital inputs
Input Types: Sourcing (PNP) or sinking (NPN)
Input Voltage: 24 VDC (typical operating range: 12–30 VDC)
Input Current: Typically 3–7 mA per channel
Isolation: Optical isolation between inputs and control logic
Response Time: Fast signal detection (<1 ms)
Connection: MIL connector
Status Indicators: LED indicators for all input channels
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-3200-2 is a 32-channel digital input module. It provides reliable, high-speed detection of discrete signals from field devices such as sensors, switches, and buttons. Each input channel is electrically isolated to ensure robust performance and protection against industrial electrical noise.

Key Features
Channels: 32 digital inputs
Input Types: Sourcing (PNP) or sinking (NPN)
Input Voltage: 24 VDC (typical operating range: 12–30 VDC)
Input Current: Typically 3–7 mA per channel
Isolation: Optical isolation between inputs and control logic
Response Time: Fast signal detection (<1 ms)
Connection: Fujitsu connector
Status Indicators: LED indicators for all input channels
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-A0004-IV is a 4-channel analog output module. Each channel supports both voltage (V) and current (I) output modes, allowing flexible integration into various industrial control systems, including motion control, process automation, and data acquisition.

Key Features
Channels: 4 analog outputs
Output Types:
– Voltage: 0–5 V, 0–10 V, ±5 V, ±10 V
– Current: 0–20 mA, 4–20 mA
Resolution: 16-bit D/A conversion
Accuracy: ±0.1% (typical)
Isolation: Optical isolation between channels and system bus
Status Indicators: LEDs for power and channel activity
Connection: Screw terminals or detachable terminal blocks
Mounting: DIN-rail (EN 50022 standard 35 mm)

The PM-A0400-IV is a 4-channel analog input module. It supports both voltage and current input ranges, making it ideal for interfacing with a wide range of analog sensors and transmitters (e.g., temperature sensors, pressure transducers, potentiometers).

Key Features
Channels: 4 analog inputs
Input Types:
– Voltage: 0–5 V, 0–10 V, ±5 V, ±10 V
– Current: 0–20 mA, 4–20 mA
Resolution: 16-bit D/A conversion
Accuracy: ±0.1% (typical)
Isolation: Optical isolation between input channels and system bus
Status Indicators: LEDs for power and channel activity
Connection: Screw terminals or detachable terminal blocks
Mounting: DIN-rail (EN 50022 standard 35 mm)

LJM10 - SKF
SN10 - NB
WB10- INA
1000-010-00 - Rexroth
• Steel grade CF53 shaft (surface treatment and chamfering is
possible)
• Induction hardened and ground linear shaft
• Shaft processing according to customer drawings

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 12 mm
Length: 4000 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 16 mm
Length: 6000 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 20 mm
Length: 6000 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 25 mm
Length: 5900 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 30 mm
Length: 5900 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 35 mm
Length: 5900 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 40 mm
Length: 5900 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

These precision-ground cylindrical shafts are mounted on a rigid aluminum support rail, ensuring easy installation and superior structural stability. The integrated support minimizes deflection, maintains precise alignment, and enables reliable operation under medium loads.

Ideal for CNC machines, 3D printers, and a wide range of automated systems, these shafts deliver smooth linear motion and long-lasting performance.

Diameter: 50 mm
Length: 5900 mm
Tolerance: h6 (high-precision fit)
Construction: Hardened and ground shaft with aluminum support rail
Select the appropriate type to match your application requirements.

Engineered for superior performance, these high-precision cylindrical shafts are manufactured from hardened steel to deliver exceptional durability, accuracy, and smooth motion. Ideal for CNC machines, 3D printers, and automated systems, they ensure reliable linear movement and efficient torque transmission even under demanding conditions.

Diameter: 10 mm
Length: 4000 mm
Tolerance: h6 (high precision fit)
Finish: Hardened and precision ground for maximum wear resistance and minimal friction

Choose from a range of steel grades to match your application requirements.

Engineered for superior performance, these high-precision cylindrical shafts are manufactured from hardened steel to deliver exceptional durability, accuracy, and smooth motion. Ideal for CNC machines, 3D printers, and automated systems, they ensure reliable linear movement and efficient torque transmission even under demanding conditions.

Diameter: 100 mm
Length: 4000 mm
Tolerance: h6 (high precision fit)
Finish: Hardened and precision ground for maximum wear resistance and minimal friction

Choose from a range of steel grades to match your application requirements.

Engineered for superior performance, these high-precision cylindrical shafts are manufactured from hardened steel to deliver exceptional durability, accuracy, and smooth motion. Ideal for CNC machines, 3D printers, and automated systems, they ensure reliable linear movement and efficient torque transmission even under demanding conditions.

Diameter: 110 mm
Length: 4000 mm
Tolerance: h6 (high precision fit)
Finish: Hardened and precision ground for maximum wear resistance and minimal friction

Choose from a range of steel grades to match your application requirements.
