In the realm of modern engineering and manufacturing, linear guideways stand as cornerstones of precision motion. These sophisticated components are engineered to guide and support linear movement in machinery and equipment, ensuring smooth, accurate, and repeatable motion across diverse industrial applications. From intricate automation systems to heavy-duty machine tools, linear guideways are critical for achieving optimal performance, enhancing efficiency, and maintaining the longevity of your valuable equipment.

- MSA55T4000H Rail Cross References HGR55T4000H (HIWIN) TR554000N (TBI) SBI55-4000L-B (SBC) R160750331 (Rexroth) HSR55A2UU+4000LHK (THK) LLRHC55-4000P3 (Ewellix) The MSA55 linear guide from PMI with High (H) accuracy grade is designed for applications that require high precision, smooth motion, and reliability under dynamic loads. It is widely used in machine tools, automation systems, 3D printers, and other industrial machinery. 690.72 € 690.72 EUR	- MSA65-DD Seal Double bidirectional End seal + Bottom seal 15.01 € 15.01 EUR	- MSA65-KK Seal Double bidirectional End seal + Bottom seal + Scraper 20.29 € 20.29 EUR	- MSA65-SL-KIT-pc Lubricator SL lubricator unit is designed with an oil reservoir which equipped with a high-density fiber net. 40.35 € 40.35 EUR
- MSA65-ZZ Seal Bidirectional End seal + Bottom seal + Scraper 10.72 € 10.72 EUR	- MSA65ESSF0H Carriage MSA65E is a carriage with installation on both (top or bottom) sides. Cross References HGW65CAZAH (HIWIN) TRH65FNNZ0 (TBI) SBI65FLNK2 (SBC) R165162310 (Rexroth) HSR65ASSC1H (THK) LLRHC65AT1P3 (Ewellix) The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 160.88 € 160.88 EUR	- MSA65ESSF1H Carriage MSA65E is a carriage with installation on both (top or bottom) sides. Cross References HGW65CAZBH (HIWIN) TRH65FNNZ0 (TBI) SBI65FLNK3 (SBC) R165162320 (Rexroth) HSR65ASSC0H (THK) LLRHC65AT2P3 (Ewellix) The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 160.88 € 160.88 EUR	- MSA65ESSFCH Carriage MSA65E is a carriage with installation on both (top or bottom) sides. Cross References HGW65CAZ0H (HIWIN) TRH65FNNZ0 (TBI) SBI65FLNK1 (SBC) R165169310 (Rexroth) HSR65ASSH (THK) LLRHC65AT0P3 (Ewellix) The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 160.88 € 160.88 EUR
- MSA65LESSF0H Carriage MSA65LE (Long Flange) is a carriage with installation on both (top or bottom) sides. Cross References HGW65HAZAH (HIWIN) TRH65FENZ0 (TBI) SBI65FLLNK2 (SBC) R165361320 (Rexroth) HSR65HASSH (THK) LLRHC65LAT0P3 (Ewellix) The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 185.20 € 185.20000000000002 EUR	- MSA65LESSF1H Carriage MSA65LE (Long Flange) is a carriage with installation on both (top or bottom) sides. Cross References HGW65HAZBH (HIWIN) TRH65FENZ0 (TBI) SBI65FLLNK3 (SBC) R165362310 (Rexroth) HSR65HASSC0H (THK) LLRHC65LAT2P3 (Ewellix) The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 185.20 € 185.20000000000002 EUR	- MSA65LESSFCH Carriage MSA65LE (Long Flange) is a carriage with installation on both (top or bottom) sides. Cross References HGW65HAZ0H (HIWIN) TRH65FEZ0 (TBI) SBI65FLLNK1 (SBC) R165362310 (Rexroth) HSR65HASSH (THK) LLRHC65LAT0P3 (Ewellix) The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 185.20 € 185.20000000000002 EUR	- MSA65LSSSF0H Carriage MSA65LS is a Long Narrow type of PMI linear guideway, can be installed from top side of carriage. Cross References HGH65HAZAH (HIWIN) TRH65VENZ0 (TBI) SBI65SLLNK2 (SBC) R162361310 (Rexroth) HSR65HRSSH (THK) LLRHC65LUT1P3 (Ewellix) The MSA S/LS represents a streamlined square-shaped carriage, offered in both standard (MSA-S) and extended (MSA-LS) lengths. Notably, mounting holes are exclusively positioned on the upper side. Specifically tailored for applications demanding both precision and robustness, the MSA Series caters to both regular and substantial load requirements. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 178.42 € 178.42000000000002 EUR
- MSA65LSSSF1H Carriage MSA65LS is a Long Narrow type of PMI linear guideway, can be installed from top side of carriage. Cross References HGH65HAZBH (HIWIN) TRH65VENZ0 (TBI) SBI65SLLNK3 (SBC) R162362310 (Rexroth) HSR65HRSSC0H (THK) LLRHC65LUT2P3 (Ewellix) The MSA S/LS represents a streamlined square-shaped carriage, offered in both standard (MSA-S) and extended (MSA-LS) lengths. Notably, mounting holes are exclusively positioned on the upper side. Specifically tailored for applications demanding both precision and robustness, the MSA Series caters to both regular and substantial load requirements. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 178.42 € 178.42000000000002 EUR	- MSA65LSSSFCH Carriage MSA65LS is a Long Narrow type of PMI linear guideway, can be installed from top side of carriage. Cross References HGH65HAZ0H (HIWIN) TRH65VENZ0 (TBI) SBI65SLLNK1 (SBC) R162369310 (Rexroth) HSR65HRSSH (THK) LLRHC65LUT1P3 (Ewellix) The MSA S/LS represents a streamlined square-shaped carriage, offered in both standard (MSA-S) and extended (MSA-LS) lengths. Notably, mounting holes are exclusively positioned on the upper side. Specifically tailored for applications demanding both precision and robustness, the MSA Series caters to both regular and substantial load requirements. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 178.42 € 178.42000000000002 EUR	- MSA65R-MM-H Rail The MSA65 linear guide from PMI with High (H) accuracy grade is designed for applications that require high precision, smooth motion, and reliability under dynamic loads. It is widely used in machine tools, automation systems, 3D printers, and other industrial machinery. Delivery Terms: - Cutting and docking are included in the product price and are performed using specialized equipment in accordance with the manufacturer's specifications to ensure precision and reliability. - The price is specified per millimeter of length. - If required, please specify the distance from the rail end to the first mounting hole (DISTANCE TO END "E"). Note: the maximum length of a single rail cannot exceed 4000 mm. Longer rails will be supplied in multiple precisely docked sections. 0.33 € 0.33 EUR	- MSA65R4000H Rail Cross References HGR65R4000H (HIWIN) TR654000N (TBI) SBI65-4000L (SBC) R160560331 (Rexroth) HSR65A2UU+4000LH (THK) LLRHC65-4000P3 (Ewellix) The MSA65 linear guide from PMI with High (H) accuracy grade is designed for applications that require high precision, smooth motion, and reliability under dynamic loads. It is widely used in machine tools, automation systems, 3D printers, and other industrial machinery. 1,013.28 € 1013.28 EUR
- MSA65SSSF0H Carriage MSA65S is a narrow type of PMI linear guideway, can be installed from top side of carriage. Cross References HGH65CAZAH (HIWIN) TRH65VNNZ0 (TBI) SBI65SLK2 (SBC) R162261310 (Rexroth) HSR65CRSSC1H(THK) LLRHC65UT1P3 (Ewellix) The MSA S/LS represents a streamlined square-shaped carriage, offered in both standard (MSA-S) and extended (MSA-LS) lengths. Notably, mounting holes are exclusively positioned on the upper side. Specifically tailored for applications demanding both precision and robustness, the MSA Series caters to both regular and substantial load requirements. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 153.24 € 153.24 EUR	- MSA65SSSF1H Carriage MSA65S is a narrow type of PMI linear guideway, can be installed from top side of carriage. Cross References HGH65CAZBH (HIWIN) TRH65VNNZ0 (TBI) SBI65SLK3 (SBC) R162262310 (Rexroth) HSR65CRSSC0H(THK) LLRHC65UT2P3 (Ewellix) The MSA S/LS represents a streamlined square-shaped carriage, offered in both standard (MSA-S) and extended (MSA-LS) lengths. Notably, mounting holes are exclusively positioned on the upper side. Specifically tailored for applications demanding both precision and robustness, the MSA Series caters to both regular and substantial load requirements. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 153.24 € 153.24 EUR	- MSA65SSSFCH Carriage MSA65S is a narrow type of PMI linear guideway, can be installed from top side of carriage. Cross References HGH65CAZ0H (HIWIN) TRH65VNNZ0 (TBI) SBI65SLK1 (SBC) R162269310 (Rexroth) HSR65CRSSH(THK) LLRHC65UT0P3 (Ewellix) The MSA S/LS represents a streamlined square-shaped carriage, offered in both standard (MSA-S) and extended (MSA-LS) lengths. Notably, mounting holes are exclusively positioned on the upper side. Specifically tailored for applications demanding both precision and robustness, the MSA Series caters to both regular and substantial load requirements. Characteristics: • Heavy Load, High Rigidity • Self Alignment Capability • Smooth Movement • Low Noise • Interchangeability. 153.24 € 153.24 EUR	- MSA65T-MM-H Rail The MSA65 linear guide from PMI with High (H) accuracy grade is designed for applications that require high precision, smooth motion, and reliability under dynamic loads. It is widely used in machine tools, automation systems, 3D printers, and other industrial machinery. Delivery Terms: - Cutting and docking are included in the product price and are performed using specialized equipment in accordance with the manufacturer's specifications to ensure precision and reliability. - The price is specified per millimeter of length. Note: the maximum length of a single rail cannot exceed 4000 mm. Longer rails will be supplied in multiple precisely docked sections. 0.33 € 0.33 EUR
- MSA65T4000H Rail Cross References HGR65T4000H (HIWIN) TR654000N (TBI) SBI65-4000L-B (SBC) R160760331 (Rexroth) HSR65A2UU+4000LHK (THK) LLRHC65-4000P3 (Ewellix) The MSA65 linear guide from PMI with High (H) accuracy grade is designed for applications that require high precision, smooth motion, and reliability under dynamic loads. It is widely used in machine tools, automation systems, 3D printers, and other industrial machinery. 1,013.28 € 1013.28 EUR	- MSB15-DD Seal Double bidirectional End seal + Bottom seal 4.21 € 4.21 EUR	- MSB15-KK Seal Double bidirectional End seal + Bottom seal + Scraper 5.38 € 5.38 EUR	- MSB15-SL-KIT-pc Lubricator SL lubricator unit is designed with an oil reservoir which equipped with a high-density fiber net. 4.34 € 4.34 EUR
- MSB15-ZZ Seal Bidirectional End seal + Bottom seal + Scraper 2.18 € 2.18 EUR	- MSB15ESSF0H Carriage Cross References EGW15CAZAH (HIWIN) TRS15FNNZ0 (TBI) SR15TBUUC1H (THK) MSB15E is a normal length low flange carriage. The mounting holes are accessible from either the top (S1) or the bottom (S2). The MSB series is used for the most compact solution for light to normal loads. The MSB series of linear guideway from PMI is a series with an installation height lower than the standard MSA series. Carriages is available in two lengths: short (MSB-TE) or normal (MSB-E). These linear guides are typically used in applications that require the most compact solution. The MSB series is preloaded from stock to 2% of the dynamic load rating. It can also be ordered with the MSAxxSL lubrication block, which is retrofitted onto the carriage and makes the carriage maintenance-free for 25,000 km under normal conditions. 26.44 € 26.44 EUR	- MSB15ESSF1H Carriage Cross References EGW15CAZBH (HIWIN) TRS15FNNZ0 (TBI) SR15TBUUC0H (THK) MSB15E is a normal length low flange carriage. The mounting holes are accessible from either the top (S1) or the bottom (S2). The MSB series is used for the most compact solution for light to normal loads. The MSB series of linear guideway from PMI is a series with an installation height lower than the standard MSA series. Carriages is available in two lengths: short (MSB-TE) or normal (MSB-E). These linear guides are typically used in applications that require the most compact solution. The MSB series is preloaded from stock to 2% of the dynamic load rating. It can also be ordered with the MSAxxSL lubrication block, which is retrofitted onto the carriage and makes the carriage maintenance-free for 25,000 km under normal conditions. 26.44 € 26.44 EUR	- MSB15ESSFCH Carriage Cross References EGW15CAZ0H (HIWIN) TRS15FNNZ0 (TBI) SR15TBUUH (THK) MSB15E is a normal length low flange carriage. The mounting holes are accessible from either the top (S1) or the bottom (S2). The MSB series is used for the most compact solution for light to normal loads. The MSB series of linear guideway from PMI is a series with an installation height lower than the standard MSA series. Carriages is available in two lengths: short (MSB-TE) or normal (MSB-E). These linear guides are typically used in applications that require the most compact solution. The MSB series is preloaded from stock to 2% of the dynamic load rating. It can also be ordered with the MSAxxSL lubrication block, which is retrofitted onto the carriage and makes the carriage maintenance-free for 25,000 km under normal conditions. 26.44 € 26.44 EUR
- MSB15R-MM-H Rail The MSB15 linear guide from PMI with High (H) accuracy grade offers a compact profile with excellent rigidity and smooth motion, making it ideal for a wide range of industrial automation, precision machinery, and equipment requiring stable linear movement in limited spaces. Delivery Terms: - Cutting and docking are included in the product price and are carried out using specialized equipment in strict accordance with PMI manufacturing requirements to ensure accuracy and durability. - The price is specified per millimeter of length. - If required, please specify the distance from the rail end to the first mounting hole (DISTANCE TO END "E"). Note: the maximum length of a single rail cannot exceed 4000 mm. Longer rails will be supplied in multiple precisely docked sections. 0.07 € 0.07 EUR	- MSB15R4000H Rail MSB-series applications Machine Center NC Lathe XYZ Axes of Heavy Cutting Machine Tools Grinding Machine Working Table Feed Shaft of Milling Machine Vertical or Horizontal Boring Machine Z Axis of Boring Machine and Machine Tools Auto Coating Machine Industrial Robot Various High Speed Material Supply Device Z Axis of Industiral Machine Binding Machine EDM Measuring Equipment Precision XY Table 257.50 € 257.5 EUR	- MSB15SSSF0H Carriage Cross References EGH15CAZAH (HIWIN) TRS15VNNZ0 (TBI) SBS15SLK2 (SBC) SR15WUUC1H (THK) MSB15S is a normal length low narrow square type carriage. Fastening holes are only accessible from the top. The MSB-Series is used for the most compact solution for light and normal loads. The MSB series of linear guideway from PMI is a series with an installation height lower than the standard MSA series. Carriages is available in two lengths: short (MSB-TS) or normal (MSB-S). These linear guides are typically used in applications that require the most compact solution. The MSB series is preloaded from stock to 2% of the dynamic load rating. It can also be ordered with the MSAxxSL lubrication block, which is retrofitted onto the carriage and makes the carriage maintenance-free for 25,000 km under normal conditions. 25.27 € 25.27 EUR	- MSB15SSSF1H Carriage Cross References EGH15CAZBH (HIWIN) TRS15VNNZ0 (TBI) SBS15SLK3 (SBC) SR15WUUC0H (THK) MSB15S is a normal length low narrow square type carriage. Fastening holes are only accessible from the top. The MSB-Series is used for the most compact solution for light and normal loads. The MSB series of linear guideway from PMI is a series with an installation height lower than the standard MSA series. Carriages is available in two lengths: short (MSB-TS) or normal (MSB-S). These linear guides are typically used in applications that require the most compact solution. The MSB series is preloaded from stock to 2% of the dynamic load rating. It can also be ordered with the MSAxxSL lubrication block, which is retrofitted onto the carriage and makes the carriage maintenance-free for 25,000 km under normal conditions. 25.27 € 25.27 EUR

Why Choose Our Linear Guideways?

Unrivaled Quality and Durability: Our linear guideways are manufactured using only the highest grades of steel and undergo stringent heat treatment processes. This meticulous approach to material selection and processing results in products that exhibit exceptional hardness, wear resistance, and load-bearing capabilities. Investing in our guideways means choosing components built to withstand the rigors of continuous operation in demanding industrial environments, minimizing downtime and maximizing the lifespan of your machinery.
Engineered for Precision and Smoothness: Precision is at the heart of our linear guideway design. Each component is manufactured to exacting tolerances, ensuring minimal friction and exceptionally smooth movement. This precision engineering translates directly into enhanced accuracy and repeatability in your applications, crucial for processes requiring intricate control and consistent results. Our guideways minimize vibration and noise, contributing to a more stable and productive operating environment.
Extensive Range and Customization: Recognizing the diverse needs of our B2B clientele, we offer a comprehensive portfolio of linear guideway solutions. Our range encompasses various types, including ball-bearing and roller guideways, in a multitude of sizes and configurations. Whether your application demands compact, lightweight solutions or heavy-duty, high-capacity systems, we have a guideway to match. Furthermore, we provide extensive customization options, allowing you to tailor guideways to your precise specifications, ensuring seamless integration and optimal performance within your unique machinery designs.

Versatile Applications Across Industries

Linear guideways are the unsung heroes behind the smooth and precise operation of countless industrial applications. Their versatility and reliability make them indispensable across a wide spectrum of sectors, including:

Advanced Manufacturing and Automation: In automated assembly lines, robotic systems, and precision manufacturing equipment, our linear guideways provide the accurate and reliable motion essential for maximizing throughput and maintaining product quality. They are integral to pick-and-place mechanisms, CNC machining centers, and automated welding systems.
Semiconductor and Electronics Industry: The delicate processes within semiconductor manufacturing and electronics assembly demand extreme precision and cleanliness. Our linear guideways, with their smooth, low-friction movement and options for cleanroom compatibility, are ideal for wafer handling, chip placement, and inspection equipment.
Medical and Laboratory Equipment: Medical devices and laboratory instruments require precise and reliable linear motion for critical functions. From medical imaging equipment like CT scanners and MRI machines to laboratory automation systems and surgical robots, our guideways ensure smooth, accurate, and dependable operation, meeting the stringent demands of the medical field.
Packaging and Printing Machinery: In high-speed packaging lines and precision printing presses, linear guideways contribute to the speed, accuracy, and reliability of material handling and printing processes. They are used in label applicators, automated filling systems, and high-resolution printing equipment.
Aerospace and Defense: The aerospace and defense industries demand components capable of withstanding extreme conditions while maintaining unwavering reliability and precision. Our linear guideways, manufactured to the highest quality standards, are utilized in aircraft control systems, simulation equipment, and specialized defense applications.

Our Services

Expert Technical Consultation: Our team of experienced application engineers possesses in-depth knowledge of linear motion technology and a wide range of industrial applications. We provide expert consultation to guide you in selecting the optimal linear guideway solution for your specific requirements, considering factors like load capacity, speed, accuracy, and environmental conditions.
Custom Engineering and Design: We understand that standard solutions may not always meet the unique demands of every application. Our engineering team offers custom design and manufacturing services, tailoring linear guideways to your precise dimensional requirements, material specifications, and performance parameters. We collaborate closely with you to develop innovative solutions that address your most challenging linear motion needs.
Installation Guidance and Maintenance Support: To ensure the seamless integration and long-term performance of your linear guideway systems, we provide comprehensive installation guidance and ongoing maintenance support. Our technical resources and expert advice help you optimize system setup, minimize downtime, and extend the operational life of your investment.
