Bearing inserts for bearing units, are proposed with different locking devices for easy assembly.
Product analogs:
INA GAY35-XL-NPP-B
SKF YAT 207
SNR US207G2

Connector Set, Power and Signal Connectors for spindle ATC71 serias

Leadshine M860 stepper driver.
Input voltage of 24 - 80 VDC.
Output current of 1.80 - 7.20 A.
M860 takes step & direction (PUL/DIR) or CW/CCW control. Stepper driver Leadshine M860 is easy to setup and configure via DIP switches.

MC500 series PLCs are compatible with Codesys and Leadsys Studio software

Motion Control
Supports EtherCAT control of 8 axes
6-axis high-speed pulse output at 200 kHz
Linear interpolation for up to 6 axes, circular interpolation for 3 axes
Advanced motion features: Electronic CAM (E-CAM), flying shear, and chasing shear

Intelligent Interconnection
Supports OPC UA and EtherNet/IP industrial communication protocols
CANopen distributed control for up to 32 nodes
Modbus and free communication port for flexible integration

Comprehensive Functionality
Local bus expansion supporting up to 32 I/O modules
Total I/O capacity up to 32,767 points
6 high-speed counters (200 kHz)
Built-in protections: over-temperature, over-voltage, and short circuit

Memory and Storage
Program Memory: 20 MB
Data Memory: 40 MB
Non-volatile Retention Area: 512 KB (for power-failure data retention)
SD Card Slot: Supports standard microSD cards (FAT32), maximum capacity up to 32 GB for program download and data storage

Digital I/O Specifications
Digital Inputs: 16 total
12 high-speed inputs (200 kHz)
4 standard inputs (1 kHz), NPN/PNP configurable
Digital Outputs: 16 total
12 high-speed outputs (200 kHz)
4 standard outputs (10 kHz), NPN type

Supported Programming Languages: ST, LD, CFC, SFC, FBD, IL

Block MGN07-CZ-0H-M is used in conjunction with the MGNR07R600HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGN07-HZ-0H-M is used in conjunction with the MGNR07R600HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGN09-CZ-1H-MEL is used in conjunction with the MGNR09R1200HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGN12-CZ-0H-M is used in conjunction with the MGNR12R2000HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGN12-HZ-0H-M is used in conjunction with the MGNR12R2000HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGN15-CZ-0H-M is used in conjunction with the MGNR15R2000HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGN15-HZ-0H-M is used in conjunction with the MGNR15R2000HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

The MGNR 07R600HM rail is compatible with MGN series blocks.
MGNR 07R rail can be cut and joined based on customer’s request, taking into account the length requirements, using high-precision equipment, using the manufacturer’s technologies, including cutting, grinding and joining of several rails.
Application: miniature device, semiconductor equipment, medical equipment.

The MGNR 09R1200HM rail is compatible with MGN series blocks.
MGNR 09R rail can be cut and joined based on customer’s request, taking into account the length requirements, using high-precision equipment, using the manufacturer’s technologies, including cutting, grinding and joining of several rails.
Application: miniature device, semiconductor equipment, medical equipment.

The MGNR 12R2000HM rail is compatible with MGN series blocks.
MGNR 12R rail can be cut and joined based on customer’s request, taking into account the length requirements, using high-precision equipment, using the manufacturer’s technologies, including cutting, grinding and joining of several rails.
Application: miniature device, semiconductor equipment, medical equipment.

The MGNR 15R2000HM rail is compatible with MGN series blocks.
MGNR 15R rail can be cut and joined based on customer’s request, taking into account the length requirements, using high-precision equipment, using the manufacturer’s technologies, including cutting, grinding and joining of several rails.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGW09-CZ-0H-M is used in conjunction with the MGWR09R1200HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGW09-HZ-0H-M is used in conjunction with the MGWR09R1200HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGW12-CZ-0H-M is used in conjunction with the MGWR12R2000HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGW15-CZ-0H-M is used in conjunction with the MGWR15R2000HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

Block MGW15-HZ-0H-M is used in conjunction with the MGWR15R2000HM profile rail.
Miniature linear guideways series MG:
1. Tiny and light weight, suitable for miniature equipment.
2. Gothic arch contact design can sustain loads from all directions and offer high rigidity and high accuracy.
Application: miniature device, semiconductor equipment, medical equipment.

The MGWR 09R1200HM rail is compatible with MGW series blocks.
MGWR 09R rail can be cut and joined based on customer’s request, taking into account the length requirements, using high-precision equipment, using the manufacturer’s technologies, including cutting, grinding and joining of several rails.
Application: miniature device, semiconductor equipment, medical equipment.

The MGWR 12R2000HM rail is compatible with MGW series blocks.
MGWR 12R rail can be cut and joined based on customer’s request, taking into account the length requirements, using high-precision equipment, using the manufacturer’s technologies, including cutting, grinding and joining of several rails.
Application: miniature device, semiconductor equipment, medical equipment.

The MGWR 15R2000HM rail is compatible with MGW series blocks.
MGWR 15R rail can be cut and joined based on customer’s request, taking into account the length requirements, using high-precision equipment, using the manufacturer’s technologies, including cutting, grinding and joining of several rails.
Application: miniature device, semiconductor equipment, medical equipment.

Double bidirectional End seal + Bottom seal

Double bidirectional End seal + Bottom seal + Scraper

SL lubricator unit is designed with an oil reservoir which equipped with a high-density fiber net.

Bidirectional End seal + Bottom seal + Scraper

MSA15E is a carriage with installation on both (top or bottom) sides.

Cross References
HGW15CAZAH (HIWIN)
TRH15FNNZ0 (TBI)
SBI15FLNK2 (SBC)
R165111420 (Rexroth)
HSR15ASSH (THK)
LLRHC15AT1P3 (Ewellix)
HRC15FNV2H (CPC)

The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load.
Characteristics:
• Heavy Load, High Rigidity
• Self Alignment Capability
• Smooth Movement
• Low Noise
• Interchangeability.

MSA15E is a carriage with installation on both (top or bottom) sides.

Cross References
HGW15CAZ0H (HIWIN)
TRH15FNNZ0 (TBI)
SBI15FLNK0 (SBC)
R165119320 (Rexroth)
HSR15ASSH (THK)
LLRHC15AT0P3 (Ewellix)
HRC15FNV1H (CPC)

The MSA-E/LE is a carriage with flange. This carriage is available in two different lengths, normal (MSA-E) or long (MSA-LE). Fastening holes are accessible either from top (S1) or bottom (S2). Full ball MSA-Series is especially suited for high precision and high rigidity required motion, for normal and high load.
Characteristics:
• Heavy Load, High Rigidity
• Self Alignment Capability
• Smooth Movement
• Low Noise
• Interchangeability.

The MSA15 linear guide from PMI with High (H) accuracy grade is designed for applications that require high precision, smooth motion, and reliability under dynamic loads. It is widely used in machine tools, automation systems, 3D printers, and other industrial machinery.

These linear guides are applicable to both MSA and SMA series from PMI.

Delivery Terms:
- Cutting and docking are included in the product price and are performed using specialized equipment in accordance with the manufacturer's specifications to ensure precision and reliability.
- The price is specified per millimeter of length.
- If required, please specify the distance from the rail end to the first mounting hole (DISTANCE TO END "E").
Note: the maximum length of a single rail cannot exceed 4000 mm. Longer rails will be supplied in multiple precisely docked sections.

Cross References
HGR15R4000H (HIWIN)
TR154000N (TBI)
SBI15-4000L (SBC)
R160510331 (Rexroth)
HSR15A2UU+4000LH (THK)
LLRHC15-4000P3 (Ewellix)

These linear guides are applicable to both MSA and SMA series from PMI.

The MSA15 linear guide from PMI with High (H) accuracy grade is designed for applications that require high precision, smooth motion, and reliability under dynamic loads. It is widely used in machine tools, automation systems, 3D printers, and other industrial machinery.

MSA15S is a narrow type of PMI linear guideway, can be installed from top side of carriage.

Cross References
HGH15CAZAH (HIWIN)
TRH15VNNZ0 (TBI)
SBI15SLK2 (SBC)
R162211420 (Rexroth)
HSR15CRSSH(THK)
LLRHC15UT1P3 (Ewellix)
HRC15MNV2H (CPC)

The MSA S/LS represents a streamlined square-shaped carriage, offered in both standard (MSA-S) and extended (MSA-LS) lengths. Notably, mounting holes are exclusively positioned on the upper side. Specifically tailored for applications demanding both precision and robustness, the MSA Series caters to both regular and substantial load requirements.
Characteristics:
• Heavy Load, High Rigidity
• Self Alignment Capability
• Smooth Movement
• Low Noise
• Interchangeability.
