PM-0016-P Digital output module
Description:
The PM-0016-P is a high-performance digital output module. Featuring 16 isolated PNP (source type) output channels, it provides a compact and efficient solution for controlling external devices such as relays, contactors, solenoids, and indicator lights.
Key Features
Channels: 16 sourcing (PNP) digital outputs
Output Type: PNP (source type)
Nominal Voltage: 24 VDC
Max Output Current: Up to 0.5 A per channel
Response Time: Fast switching with <1 ms delay
Isolation: Optical isolation between field outputs and logic circuit
Status Indicators: LED indicators for each output channel
Mounting: DIN-rail (EN 50022 standard 35 mm)
Technical information:
| Brand:LEADSHINE |
